6069 rim material with 30mm internal width, delivers impressive rim durability and impact resistance
4.5mm offset improves spoke (32h) tension balance, increasing wheel stiffness and strength
Trace hubs deliver eMTB rated strength for every rider with 10 degrees of engagement
Super strong steel axle
Steel cassette body
10-degree engagement
2105g (27.5")
2190g (29")
Hub Model |
Trace |
Position |
Rear |
Wheel Tire Type |
Tubeless Ready |
Rim Model |
Aeffect R 30 |
Rim External Width |
34mm |
Spoke Type |
J-Bend |
Wheel Diameter/ISO |
27.5 / 584 |
Rim Internal Width |
30mm |
Freehub Body |
Shimano Micro Spline |
Rim inner width range |
28-34.9mm |
Hub Spacing |
148mm |
Rim Color |
Black |
Rim Construction |
Double wall |
Rim Material |
Aluminum |
Axle Type |
12x148mm TA |
Rim Drilling |
32 |
Wheel-Brake Comp. |
Disc IS 6-bolt |
