Description
Technical Specifications
Frameset
Frame
A1 Premium Butted Alloy, unisex frame, internal cable routing, 148mm thru-axle, 30.9mm dropper post ready, replaceable derailleur hanger compatible
Fork
A1 Premium Butted Alloy, Alloy steerer, 15x110 mm, W/Mini Fender
Seat Binder
Bolt-type, 34.9mm
Cockpit
Saddle
Kids Bridge Saddle, 130mm
SeatPost
Alloy, 0mm offset, 2-bolt clamp, 30.9mm, 300mm length
Stem
3D Forged Aluminim, 35mm length, 6-degree rise, 31.8mm clamp diameter
Handlebars
Mini Rise, Alloy Double Butted, 6-degree Backsweep, 600mm Width, 31.8mm , 19mm Bar End Diameter
Grips
Specialized Trail Grips, 19mm bar end diameter, lock-on
Brakes
Front Brake
C-STAR Hydraulic Disc Brake, 160mm rotor, adjustable reach
Rear Brake
C-STAR Hydraulic Disc Brake, 160mm rotor, adjustable reach
Drivetrain
Shift Levers
microSHIFT SL-M9295, 9-speed
Rear Derailleur
microSHIFT Advent RD-M618M, 9-speed w/o Clutch
Chain
KMC X9EPT, Anti-corrosion coating , Missing Link™
Cassette
microSHIFT Advent, 9-speed, 11-42t
Crankset
Forged Alloy, 115mm length, narrow Q-factor, w/ chainguard
Chainrings
Alloy 30T, narrow-wide design
Bottom Bracket
Square-tapered, 68mm
Accessories
Pedals
Nylon platform w/ reflectors
Wheels & Tires
Rims
Alloy, 16mm depth, 25mm internal width, 28H
Front Hub
Alloy, 6-Bolt, 28H, 15x110 Boost
Rear Hub
Alloy, 6-Bolt, 28H, 12x148 Boost, 11-speed compatiable
Front Tire
Ground Control Sport, 20x2.35"
Rear Tire
Ground Control Sport, 20x2.35"
Spokes
Stainless, 14g
Inner Tubes
Schrader valve
* Weights based on production painted frames as pictured. Actual weights will vary based on colorway, frame size, and component variation. Specifications are subject to change without notice.
