Description
Technical Specifications
Frameset
Frame
Specialized A1 premium butted alloy, zero-stack head tube, internal cable routing, 135x9mm forged dropouts, chainstay-mounted disc brake, replaceable alloy derailleur hanger, stealth rack mounts, dropper post compatible
Seat Binder
Alloy, quick release, 34.9
Suspension
Fork
RockShox Judy, Solo Air, Turnkey damper, 46mm offset, QR, 80/90/100mm travel (size-specific), steel steerer
Brakes
Front Brake
Shimano BR-MT200, hydraulic disc ,180/160mm
Rear Brake
Shimano BR-MT200, hydraulic disc, 160 mm
Drivetrain
Shift Levers
Shimano Deore, RapidFire Plus, 10-speed
Rear Derailleur
Shimano Deore, RD-M5120, 10-speed
Cassette
Sunrace, 11-46t, 10spd
Chain
KMC, X10, EPT anti-corrosion coating, 10-speed w/ Missing Link™
Crankset
Stout 1x, forged alloy
Bottom Bracket
Square-tapered, 73mm, internal bearings, 122.5mm spindle
Wheels & Tires
Rims
Specialized Alloy, hookless, Tubeless ready, 25mm inner width
Front Hub
Formula DC-20, 6-Bolt, disc, 100x9mm spacing, quick-release
Rear Hub
Formula DC-22, 6-Bolt freehub, disc, 135x9mm spacing, quick-release
Spokes
Stainless, 14g
Front Tire
Fast Trak Sport, 650b/29x2.35"
Rear Tire
Fast Trak Sport, 650b/29x2.35"
Inner Tubes
Standard 40mm PV 650B/29x1.75-2.4
Cockpit
Stem
Stout 3D-forged alloy, 31.8mm, 6-degree rise
Handlebars
Specialized, alloy, 9-degree backsweep, 15mm rise, 31.8mm
Grips
Specialized Trail Grips, lock-on
Saddle
Bridge Sport, Steel rails, 155/143mm
SeatPost
Alloy, 2-bolt clamp, 30.9mm
Weight
Weight
12.58 kg (27 lb, 11.7 oz)
Weight Size
MD
* Weights based on production painted frames as pictured. Actual weights will vary based on colorway, frame size, and component variation. Specifications are subject to change without notice.
