Description
Technical Specifications
Frameset
Frame
Specialized A1 premium butted alloy, zero-stack head tube, internal cable routing, 135x9mm forged dropouts, chainstay-mounted disc brake, replaceable alloy derailleur hanger, stealth rack mounts, dropper post compatible
Seat Binder
Alloy, quick release, 34.9
Suspension
Fork
SR Suntour XCM 27.5, 30mm stanchions, Rx Tune, coil spring, QR, 80/90/100mm travel (size-specific), 42mm offset
Brakes
Front Brake
Shimano BR-MT200, hydraulic disc, 180mm
Rear Brake
Shimano BR-MT200, hydraulic disc, 180mm
Drivetrain
Shift Levers
Microshift, SL-M859R, 2x9
Front Derailleur
microSHIFT FD-M462, 2-speed
Rear Derailleur
Microshift RD-M46L, 9spd
Cassette
SunRace, 9-Speed, 11-36t
Chain
KMC X9EPT, 9-speed, anti-corrosion coating w/ reusable Missing Link™
Crankset
Stout 2x, forged alloy
Bottom Bracket
Square-tapered, 73mm, internal bearings, 122.5mm spindle
Wheels & Tires
Rims
Specialized alloy, disc only, double-wall, 25mm inner width, 32h
Front Hub
Formula 6-Bolt, disc, 100x9mm spacing, quick-release, 32H
Rear Hub
Formula SP-2125, 6-Bolt freehub, disc, 135x9mm spacing, quick-release
Spokes
Stainless, 14g
Front Tire
Fast Trak Sport, 27.5 x 2.35"
Rear Tire
Fast Trak Sport, 27.5 x 2.35"
Inner Tubes
Schrader, 40mm valve
Cockpit
Stem
3D-forged alloy, 31.8mm, 7-degree rise
Handlebars
Stout Mini Rise, alloy, 9-degree backsweep, 15mm rise, 31.8mm
Grips
Specialized MTB Grip, lock-on
Saddle
Bridge Sport, Steel rails, 155/143mm
SeatPost
Alloy, 2-bolt clamp, 30.9mm
Accessories
Pedals
Specialized Platform Pedal
* Weights based on production painted frames as pictured. Actual weights will vary based on colorway, frame size, and component variation. Specifications are subject to change without notice.
