Description
Technical Specifications
Frameset
Frame
Specialized A1 premium butted alloy, zero-stack head tube, internal cable routing, 135x9mm forged dropouts, chainstay-mounted disc brake, replaceable alloy derailleur hanger, stealth rack mounts, dropper post compatible
Seat Binder
Alloy, quick release, 34.9
Suspension
Fork
SR Suntour XCM 29, 30mm stanchions, Rx Tune, coil spring, QR, 90/100mm travel (size-specific), 42mm offset
Brakes
Front Brake
Tektro BR-M275 Hydraulic Disc, 180/160mm
Rear Brake
Tektro BR-M275 Hydraulic Disc, 160mm
Drivetrain
Shift Levers
Shimano CUES SL-U4000-9R,RAPIDFIRE PLUS
Rear Derailleur
SHIMANO REAR DERAILLEUR, RD-U4000, CUES, GS 9-SPEED, TOP NORMAL, SHADOW DESIGN
Cassette
SHIMANO CUES CS-LG300-9, 9-SPEED, 11-41T
Chain
SHIMANO CN-LG500, W/QUICK-LINK
Crankset
Stout 1x, forged alloy
Bottom Bracket
Square-tapered, 73mm, internal bearings, 122.5mm spindle
Wheels & Tires
Rims
Specialized alloy, disc only, double-wall, 25mm inner width, 32h
Front Hub
Formula SP-2120 6-Bolt, disc, 100x9mm spacing, quick-release
Rear Hub
Formula SP-2125, 6-Bolt freehub, disc, 135x9mm spacing, quick-release
Spokes
Stainless, 14g
Front Tire
Fast Trak Sport, 650b/29x2.35"
Rear Tire
Fast Trak Sport, 650b/29x2.35"
Inner Tubes
Standard 40mm SV 650B/29x1.75-2.4
Cockpit
Stem
3D-forged alloy, 31.8mm, 7-degree rise
Handlebars
Stout Mini Rise, alloy, 9-degree backsweep, 15mm rise, 31.8mm
Grips
Specialized Trail Grips, lock-on
Saddle
Bridge Sport, Steel rails, 155/143mm
SeatPost
Alloy, 2-bolt clamp, 30.9mm
Accessories
Pedals
Specialized Flat Pedal
Product Details
Product ID
221599
Weight
Weight
13.38 kg (29 lb, 8.0 oz)
Weight Size
MD
* Weights based on production painted frames as pictured. Actual weights will vary based on colorway, frame size, and component variation. Specifications are subject to change without notice.
